Hot Filling/Warm Bottle Filler Bottled Water Carbonated Soft Juice Drink Bottling Filling Machine Bottle Washing Filling Capping Labeling Packing Machine

Hot Filling/Warm Bottle Filler Bottled Water Carbonated Soft Juice Drink Bottling Filling Machine Bottle Washing Filling Capping Labeling Packing Machine

Product Description The machine is special used for PET bottle hot filling; adopts high speed rotary automatic bottle ri;
Basic Info.
Model NO. RCGN series
Feed Cylinder Structure Single-Room Feeding
Dosing Device Rotor
Filling Principle Hot Filling
Packaging Container Lifting Structure Pneumatic Lifting
Structure Rotary
Packaging Bottle
Packaging Material Plastic
Bottle Size 200ml to 2000ml
Delivery Time 90days
Power Customized
Feature High Efficiency
Cap Type Ropp Cap , Normal Cap
Weight 3t
Dimensions 2500*2000*2000
Configuration Europe Brand
Certification CE, ISO, SGS
Model Rcgn 18-18-6
Suitable Product Juice /Tea/ Dairy Drink
Capacity 2000bph-24000bph
PLC Siemens (Germany) / Mitsubishi (Japan)
Valve Hot Filling/Warm Filling
Control System PLC+ Remote Operation System
Transport Package Wooden Case
Specification Stainless Steel 304/316
Trademark HY-FILLING
Origin China
HS Code 8422301090
Production Capacity 30sets/Year
Product Description
Product Description
The machine is special used for PET bottle hot filling; adopts high speed rotary automatic bottle rinsing, bottle neck clip conveyor manner, gravity filling, negative pressure liquid-back, automatic control of material temperature (feed or return) rinsing/filling/capping three-in-one machine.
Detailed images
Rinsing part
The machine is rotary rinsing machine, mainly used for rinsing beverage, mineral water bottles etc. The new bottle enters into the equipment through bottle distribution screw and star wheel, and its neck is clipped to mouth down by the clamp and turner device, dry after rinsing, and turn to mouth up automatically, then enters into the filling machine through bottle-outlet star wheel conveyor.
Filling Part
It is advanced unique filling valve, no spring in the valve, and no touch with the spring for the products, which will help the cleaning of the internal valve. PLC control, frequency control; bottle neck clip filling technologies; upper cylinder and lower recycle cylinder is connected with hard pipe; gravity filling, negative pressure reflux; unique material temperature control system and liquid level automatic inspection.
Capping part
The capping is magnetic capping, with overload protection function, stable and reliable capping torque. Import motor gear box, reduce the secondary pollution of the bottle cap, 304 stainless steel cap chute tank, cap silo and cap chute tank with electronic capless inspection system, automatic control cap conveyor machine and running speed for the machine.

Technical parameter:
Rated Capacity2000-40000BPH (500ml)
Filling MethodHot Filling
Applicable BottlePET Bottle, Diameter 50-100mm, Height 150-320mm
Applicable CapNormal Standard Cap
Air Supply Pressure0.6 MPa
Rinsing Water Pressure0.2~0.25 MPa
Filling Temperature85-90ºC
Rated Voltage380V

We provide the Complete turnkey project for beverage production line includes:
  1. Water Treatment System (Water Filtration)
  2. Preparation/Processing System (Mixing System for Drinks like CSD, juice etc)
  3. Injection molding machines (for pet preform)
  4. Bottle Blowing Machine (Making plastic bottles)
  5. Air Conveyor (Transport empty bottles)
  6. Filling Machine (Filling product into bottles)
  7. Cap elevator (Transport cap)
  8. Blow dryer (Blow away water drops)
  9. Flat Convey (Transport bottle)
  10. Code Printer (Printing the date on the filled bottle)
  11. Labeling Machine (Labeling for filled bottle)
  12. Bottle Packing Machine (package the filled bottles)
  13. Palletizing Machine (to palletize the cartons)
Beverage/liquid production line
1.Water treatmentWater treatment is equipped for pure water, mineral water, and water used in beverage drink. It contains RO, natrium filter, ultra filter, activated carbon filter, ion exchanger, ozone processor etc.
2.Bottle Blowing Machine Divided into: semi-automatic bottle blowing and full automatic bottle blowing machine.Suitable for: PET bottle.Bottle size: 500ml-2L
3. Filling MachineThe machine is combined with rinsing, filling and capping, which special designed for PET bottled. It is stable characteristic, advanced technology, nice appearance and complete function.
4.Filled Bottle Conveyor SystemConveying belt is designed by module, component can be interchanged easily, structure is compact, noise is little, easy assembling and maintaining, have flexibility to combine the bottle type according to the different capacity.
5.Packaging System Customized: Sleeving Label Machine, Film Shrink-wrapping Machine, Palletizing machine, Date code printer etc.
